Essential Tile Installation Tools: What You Need to Lay Tile

The right tile installation tools make it easier to measure, cut, set, space, grout, and finish tile accurately. What you actually need depends on the tile material, format, substrate, layout, and type of installation, so a professional installer’s toolkit may be considerably larger than what is required for a straightforward DIY project.

This guide covers the essential tools used throughout the tile installation process, from initial layout and mortar preparation through cutting, setting, grouting, and cleanup.

Measuring and Layout Tools

Accurate installation begins before mortar is mixed. Measuring and layout tools help establish reference lines, plan tile placement, locate cuts, and maintain the intended layout as installation progresses.

Tape Measure

A tape measure is essential for measuring the installation area, determining tile placement, locating obstacles, and marking individual tiles for cutting.

Levels and Layout Tools

Levels, straightedges, squares, chalk lines, lasers, and other layout tools can help establish reference lines and check the installation area. The particular tools needed depend on whether you're working on a floor, wall, shower, or other surface.

Mortar Mixing and Application Tools

Setting tile requires more than simply spreading mortar onto a surface. Mixing equipment and appropriate trowels help prepare and apply setting materials according to the manufacturer's requirements.

Mortar Mixer and Mixing Paddle

A suitable mortar mixer and paddle makes it easier to mix setting materials consistently and according to the manufacturer's specified procedure.

Different mortars can have specific requirements for water quantity, mixing speed, mixing time, slaking, and remixing. Always follow the setting-material manufacturer's instructions rather than judging the mixture by appearance alone.

Notched Trowels

Tile trowels are used to apply and comb setting material. They are available in different notch shapes and dimensions to accommodate different materials and installation requirements.

The objective is not simply choosing a trowel based on tile dimensions. The trowel and application technique must provide the mortar coverage required for the particular installation.

Margin Trowel

A margin trowel is a useful companion to a notched trowel. It can be used for handling setting material, working in confined areas, scraping buckets, and other installation tasks where a larger notched trowel is inconvenient.

Tile Cutting Tools

Most tile installations require cuts around walls, corners, plumbing, fixtures, transitions, or other obstacles. The correct cutting tool depends on the tile material, thickness, dimensions, and type of cut.

Manual Tile Cutter

A manual tile cutter scores the tile surface and then applies breaking pressure along the score line. Compatible ceramic and porcelain tiles can often be cut quickly without electricity or water.

Manual cutters are particularly useful for repetitive straight cuts, but cutting capability varies by cutter and tile. Tile thickness, surface texture, hardness, format, and the dimensions of the required cut all matter.

Wet Tile Saw

A wet tile saw uses a diamond blade with water delivered to the cutting area. Depending on the saw, blade, and material, it can be used for straight cuts and other cuts that may not be practical with a score-and-snap cutter.

Water helps cool the blade and suppress airborne dust generated at the cutting point. The saw and blade must be suitable for the material and intended cutting method.

Tile Nippers

Tile nippers remove small portions of material and can be useful for shaping certain tiles or making adjustments that would be difficult with a manual cutter.

They are generally a supplementary cutting tool rather than a replacement for a manual cutter or tile saw.

Diamond Core Bits and Drill Bits

Diamond core bits are used to create holes for pipes, valves, fixtures, fasteners, and other penetrations.

Select the bit according to the tile material, required hole diameter, equipment, and whether the manufacturer specifies wet or dry drilling.

Diamond Blades

The blade is just as important as the saw or grinder driving it. Diamond blades are manufactured for different materials and cutting applications, so a blade intended for one type of tile may not provide the desired performance on another.

Check material compatibility, blade diameter, arbor, maximum RPM, and wet or dry rating before use.

Tile Spacing and Lippage-Control Tools

Once tile setting begins, installers need tools for maintaining the planned grout joints and controlling the relative elevation of adjacent tile edges.

Tile Spacers

Tile spacers help maintain consistent grout-joint dimensions as tiles are positioned. They are available in different sizes and designs for different installation requirements.

The spacer itself should not determine an appropriate grout-joint width. Tile characteristics, installation requirements, applicable standards, and manufacturer recommendations should be considered when planning the joint.

Tile Leveling Systems

Tile leveling systems, also commonly described as lippage-control systems, help maintain the relative elevation of adjoining tile edges while the setting material cures.

Systems may use clips and wedges, caps, straps, or other mechanisms. They can be particularly useful with larger tile but do not replace substrate preparation, correct mortar application, or proper tile-setting technique.

Our guide to when to use a tile leveling system explains where these systems are most useful and what they cannot correct.

Grouting Tools

After the tile has been set and the installation is ready for grouting according to the applicable product instructions, a separate group of tools is used to fill and finish the grout joints.

Grout Float

A grout float has a rubber or similar working surface designed to spread grout across the tile and work it into the joints. Different float designs are available for different grout and tile applications.

Grout Sponge

A grout sponge is designed for grout cleanup and finishing. Its dense construction makes it better suited to tile work than many ordinary household sponges.

Follow the grout manufacturer's instructions for washing procedure, timing, water use, and final cleanup.

Grout Wash Bucket

Professional grout-washing systems can include buckets, rollers, grids, and specialized sponges designed to improve the washing process on larger installations.

These aren't necessary for every project, but they can make repeated grout cleanup more efficient when working across larger areas.

Tile Finishing and Edge Tools

Some installations require additional work after tile has been cut, particularly where finished edges will remain visible.

Polishing and Finishing Pads

Compatible diamond hand pads and polishing products can be used for edge finishing on suitable tile and stone materials. The appropriate abrasive and polishing process depend on the material and desired finish.

Not every tile edge can or should be polished, so confirm that the material and finish are suitable before modifying exposed edges.

Safety and Comfort Equipment

Tile installation involves kneeling, lifting, cutting, drilling, mixing, and exposure to materials that require appropriate handling. Safety equipment should be selected for the particular work being performed.

Knee Pads

Knee pads provide protection and support during floor installations and other tasks that require extended kneeling. For professional installers who spend substantial time working on floors, fit and support can be particularly important.

Eye, Hearing, and Respiratory Protection

Cutting, grinding, drilling, demolition, and mixing can create flying particles, noise, and airborne dust. Appropriate eye, hearing, and respiratory protection should be selected according to the equipment, material, work environment, and applicable safety requirements.

Cutting materials containing crystalline silica requires particular attention to dust-control practices. Use equipment and engineering controls appropriate for the work being performed.

Which Tile Installation Tools Do You Actually Need?

You do not necessarily need every tool in this guide for every installation. Start by considering the tile, installation area, substrate, layout, and cuts required.

Choosing Professional Tile Installation Tools

Professional installers generally need a broader selection of equipment because tile materials, formats, layouts, and jobsite conditions change from project to project. A single cutter, trowel, blade, or spacer cannot cover every installation.

When choosing tools, consider compatibility and capability before convenience. Cutting capacity, tile thickness, material compatibility, trowel dimensions, blade specifications, tool ergonomics, replacement components, and jobsite portability can all affect which equipment makes sense.
