At a Glance
Why Choose This Product
Supports a continuous transition between the bathroom and shower when properly installed.
Provides a consistent slope toward the drain without forming a mortar bed.
Delivers inherent waterproofing through the base's closed-cell foam construction.
Connects mechanically to compatible 2" waste pipes without glue at the drain connection.
Includes Building Panels for one long wall and two short walls up to 80" high.
Supplies 53 sq. ft. of S-DRY membrane for the curbless floor transition.
Offers seven size and drain configurations for different shower plans.
Includes fasteners, outside corners, plumbing seals, and a corner putty knife.
Product Information
wedi Fundo Curbless Shower Kits provide coordinated waterproofing components for constructing tiled showers with a curb-free entrance. Each kit centers on a strong, pre-sloped Fundo shower base designed to integrate with the surrounding bathroom floor through proper subfloor preparation.
The shower base provides a consistent slope toward the selected center or off-center drain location, eliminating the need to form a traditional mortar-bed slope. The included Fundo Click and Seal drain unit uses a mechanical compression connection with compatible 2" PVC, ABS, or cast-iron waste pipes.
wedi Building Panels cover one long wall and two short walls up to 80" high. The included 53 sq. ft. S-DRY membrane and outside corners extend waterproofing beyond the shower base, while the mixing valve collar and pipe seal address common plumbing penetrations through the walls.
Seven configurations cover footprints from 36" x 48" through 48" x 72". Most models use a center drain, while the 36" x 60" size is also available with an off-center drain. This selection helps installers match the shower system to the planned enclosure and plumbing arrangement.
Common Questions
Each kit includes a pre-sloped Fundo Curbless shower base, Building Panels for three walls, Click and Seal drain unit, 53 sq. ft. of S-DRY membrane, outside corners, a 100-count fastener kit, corner putty knife, mixing valve collar, and pipe seal.
Seven configurations are available: 36" x 48" center, 36" x 60" center, 36" x 60" off-center, 42" x 42" center, 48" x 48" center, 48" x 60" center, and 48" x 72" center. Choose the footprint and drain location that match the framing and plumbing plan.
The pre-sloped Fundo Curbless base is typically recessed into the subfloor so its perimeter aligns with the adjoining bathroom floor. Proper framing, subfloor preparation, and waterproofing create the curb-free transition. wedi also offers a separate recess installation kit for suitable wood-framed floors.
The wedi Fundo drain cover, S-DRY SEAL, and wedi Joint Sealant are sold separately. These products should be selected before installation so the drain finish, membrane connections, panel seams, fasteners, and other required waterproofing transitions can be completed according to wedi instructions.
The included Fundo Click and Seal drain unit uses a mechanical compression connection with compatible 2" PVC, ABS, or cast-iron floor waste pipes. The drain connection itself does not require glue or sealant. Plumbing placement and the completed connection must still follow wedi instructions and applicable codes.
wedi states that the pre-sloped surface can accept square tile as small as 2" x 2" as well as large-format tile. Select a compatible cement-based or epoxy-based tile adhesive intended for wet areas and follow wedi requirements for the selected tile and installation conditions.
Building Panels are supplied for one long shower wall and two short walls up to 80" high. Each kit also includes 53 sq. ft. of S-DRY membrane for waterproofing the adjoining floor area required by the planned curbless shower layout.
Yes. wedi allows the shower base to be cut to size, but the perimeter channel may need to be recreated and the drain must remain properly aligned with the waste pipe. Follow the wedi installation manual or obtain project-specific guidance before altering the base.
