Raimondi Gladiator 105 Wet Bridge Tile Saw
Fast Shipping
Easy Returns
Secure Checkout
At a Glance
Quick Decision Guide
Straight Cut Capacity
41"
Diagonal Cut Capacity
29" × 29"
Maximum Single-Pass Thickness
3 1/8"
Maximum Double-Pass Thickness
6"
Blade Capacity
Up to 10"
Bevel Cutting
0° to 45°
Motor
1.5 HP, 110V
Water Basin Capacity
10 Gallons
Why Choose This Product
Key Benefits
Large Format Capacity
Makes straight cuts up to 41" and diagonal cuts up to 29" × 29"
Deep Cutting
Cuts material up to 3 1/8" in one pass or 6" using a double pass
Bevel Capability
Tilting motor assembly supports cuts from 0° to 45°
Optimized Cutting Power
Belt-drive system improves motor torque and cutting capacity
Precision Movement
Four-pulley sliding motor assembly provides controlled travel along the rail
Effective Blade Cooling
Heavy-duty pump and dual water jets cool the blade during cutting
Jobsite Durability
Cast and extruded aluminum framework provides a rigid working platform
Easy Transport & Maintenance
Wheel kit, telescopic legs and removable water basin simplify jobsite use
Product Information
Product Details
Specifications
Brand
Raimondi®
Part Number
WSGLA105
UPC
8024648055910
Product Type
Wet Bridge Tile Saw
Model
Gladiator 105
Straight Cut Capacity
41"
Diagonal Cut Capacity
29" × 29"
Maximum Cut Thickness
3 1/8" Single Pass / 6" Double Pass
Blade Capacity
9" to 10"
Blade Arbor
5/8"
Bevel Cutting
0° to 45°
Motor
1.5 HP, 110V
Blade Speed
2,400 RPM
Drive System
Belt Drive
Water Basin Capacity
10 Gallons
Water Cooling
Heavy-Duty Pump with Dual Jet Nozzles
Dimensions
57" × 27" × 31"
Weight
141 lbs
Suitable Materials
Porcelain, Granite, Marble, Ceramic Tile, Brick & Cement
Included
10" Porcelain Blade, Blade Reducer, Wheel Kit, Key Kit, Wrench & Manual
About This Product
41" Cutting Capacity for Large Format Tile
The Raimondi® Gladiator 105 Wet Bridge Tile Saw is designed for professional cutting of porcelain, granite, marble, ceramic tile, brick, cement, and other dense materials. It provides up to a 41" straight cutting capacity and handles tiles up to 29" × 29" on diagonal cuts, making it well suited for large-format tile installation and fabrication work.
Deep Cutting and 0° to 45° Bevel Capability
The Gladiator 105 cuts material up to 3 1/8" thick in a single pass and up to 6" thick using a double pass. Its motor assembly tilts from 0° to 45° for bevel cutting, while adjustable cutting depth provides additional control for different materials and applications.
Belt-Driven Motor and Precision Sliding System
A 1.5 HP, 110V belt-driven motor uses a Poly-V drive system to optimize torque and cutting capacity. The sliding motor assembly travels along an extruded aluminum rail using four polypropylene pulleys with reinforced double bearings. A re-adjustable square helps maintain cutting precision as the saw is used over time.
Water Cooling and 10-Gallon Removable Basin
A heavy-duty water pump supplies two adjustable jet nozzles for blade cooling during wet cutting. The removable 10-gallon polypropylene water basin simplifies cleaning and maintenance, while the cast and extruded aluminum framework provides a rigid structure for demanding jobsite use.
10" Blade Capacity and Jobsite Transport
The Gladiator 105 accommodates 10" blades with a 5/8" arbor and can also accept blades as small as 9". The supplied 10" porcelain diamond blade has a 1" arbor, with the required reducer included. Telescopic legs incorporate a safety device to help prevent collapsing, and the included wheel kit makes transporting the saw around the jobsite easier.
Common Questions
Frequently Asked Questions
What is the maximum cutting length of the Raimondi Gladiator 105?
The Gladiator 105 provides a straight cutting capacity of up to 41". It can also make diagonal cuts on tiles up to 29" × 29".
How thick of a tile can the Gladiator 105 cut?
The saw can cut material up to 3 1/8" thick in a single pass and up to 6" thick using a double pass.
What materials can the Raimondi Gladiator 105 cut?
The Gladiator 105 is designed for cutting porcelain, granite, marble, ceramic tile, brick, cement, and similar materials.
Can the Gladiator 105 make bevel cuts?
Yes. The motor assembly tilts from 0° to 45° for bevel cutting, and the cutting depth is adjustable.
What size blade does the Gladiator 105 use?
The saw accommodates blades up to 10" in diameter with a 5/8" arbor and can use blades as small as 9". The supplied 10" porcelain blade has a 1" arbor, and the required reducer is included.
What are the motor specifications?
The Gladiator 105 uses a 1.5 HP, 110V belt-driven motor. The motor operates at 3,360 RPM, with a listed blade rotation speed of 2,400 RPM.
How is the blade cooled during cutting?
A heavy-duty water pump supplies two jet nozzles that direct water to the blade for cooling during wet cutting. The saw includes a removable 10-gallon polypropylene water basin.
What comes with the Raimondi Gladiator 105?
The saw includes a 10" porcelain diamond blade, blade reducer, transport wheel kit, key kit, wrench, and manual.
