BARWALT PLS Max Tile Leveling System

Leveling Clips and Reusable Wedges for Tile Up to 14 mm

$12.88

In Stock

6 in stock and ready to ship.

MPN:
HDWTLS15
UPC:
035965330664

Free Shipping Over $200 Details

Contractor Discount Eligible Learn More

At a glance

Full specifications
Item Type
Spacer Bases
Grout Joint
1/16"
Quantity
200
Maximum Tile Thickness
14 mm

Complete your setup

Product Benefits

  • Reduced Tile Lippage Keeps adjoining tile surfaces aligned while thinset cures
  • Consistent Grout Joints Spacer bases maintain the selected joint width
  • Two Clip Sizes Choose 1/16" or 1/8" tile leveling clips
  • 14 mm Tile Capacity Works with wall and floor tile up to 14 mm thick
  • Wall & Floor Use Supports horizontal and vertical tile installations
  • Reusable Wedges Retain wedges for use on future tile projects
  • Controlled Removal Spacer bases break away along the grout joint after curing
  • Multiple Pack Sizes Available in 200-piece bags and contractor bulk boxes

Specifications

Brand
BARWALT®
Part Number
HDWTLS15
UPC
035965330664
Product Type
Tile Leveling Spacer Bases
System
PLS Max™
Item Type
Spacer Bases
Grout Joint Size
1/16"
Quantity
200
Maximum Tile Thickness
14 mm
Application
Wall & Floor Tile
Leveling Function
Helps Reduce Tile Lippage
Spacing Function
Maintains Consistent 1/16" Grout Joints
Removal Method
Strike Along Grout Joint with Rubber Mallet After Thinset Dries
Compatible Wedges
PLS Max™ Reusable Wedges
Compatible Pliers
PLS™ Pliers BWTLSP
Optional Tile Protection
Anti-Scratch Disks DSPIN100
Packaging
Resealable Bag

Product details

The BARWALT® PLS Max Tile Leveling System uses 1/16" or 1/8" spacer bases with reusable wedges to reduce lippage and maintain consistent joints on wall and floor tile up to 14 mm thick. Spacer bases, wedges, PLS Pliers, and Anti-Scratch Disks are sold separately.

Tile Leveling System for Wall and Floor Installations

The BARWALT® PLS Max™ Tile Leveling System helps reduce tile lippage and maintain consistent grout joints while the thinset cures. Designed for wall and floor tile up to 14 mm thick, the system uses spacer bases and reusable wedges to keep adjoining tiles aligned during installation.

1/16" and 1/8" Tile Leveling Clips

PLS Max spacer bases, also called tile leveling clips, are available for 1/16" and 1/8" grout joints. After the thinset has dried, strike the exposed spacer base with a rubber mallet in line with the grout joint to break it away while retaining the wedge for future installations.

Reusable Wedges and Optional Installation Accessories

The reusable tile leveling wedges can be tightened with BARWALT PLS™ Pliers for controlled pressure during installation. Anti-Scratch Disks can be placed beneath the wedges to help protect tile surfaces from scratches and marks. Spacer bases, wedges, PLS Pliers, and Anti-Scratch Disks are each sold separately.

Resealable Bags and Contractor Bulk Boxes

Spacer bases and wedges are available in resealable bags containing 200 pieces. For larger installations, 1/16" and 1/8" straight spacer bases are available in 1,000-piece bulk boxes, while reusable wedges are available in 500-piece bulk boxes.

Product questions

What tile thickness works with the BARWALT PLS Max Tile Leveling System?

PLS Max is designed for wall and floor tile up to 14 mm thick.

What grout joint sizes are available for PLS Max clips?

PLS Max straight spacer bases are available for 1/16" and 1/8" grout joints.

Are the PLS Max spacer bases and wedges sold together?

No. The spacer bases and reusable wedges are sold separately, allowing installers to purchase the sizes and quantities needed for the project.

Are BARWALT PLS Max wedges reusable?

Yes. After the spacer bases are removed, the wedges can be saved and reused on future tile installations.

How are PLS Max spacer bases removed?

After the thinset has dried, strike the exposed spacer base with a rubber mallet in line with the grout joint. The base will break away while the wedge is retained.

Can PLS Max be used on walls and floors?

Yes. The tile leveling system is designed for both wall and floor installations.

What accessories are available for the PLS Max system?

BARWALT PLS Pliers can be used to tighten the wedges, while Anti-Scratch Disks help protect tile surfaces from scratches and marks. Both accessories are sold separately.

What package quantities are available?

Spacer bases and wedges are available in resealable bags of 200. Bulk spacer bases are packaged in boxes of 1,000, while bulk wedges are packaged in boxes of 500.
